New turbo forTransporter T4 1.9 TD 95 ->03

Details about : New turbo forTransporter T4 1.9 TD 95 ->03

New turbo-compressor without exchange, on original Garrett assembly with oil return hose fastened with a flange.

For VW Transporter T4, Multivan
1.9 turbo Diesel 68hp engine (ABL)
Years: 03/1995 ->06/2003
from chassis no.
70-SX-075 001->
or
70-SH-105 001->

Precautions must be taken when replacing a turbocharger:
- The oil system must be cleaned to remove any residue which may block it
- The oil and oil filter must be replaced
- The oil inlet and return ducts must be checked and cleaned
- The air hoses and breather hose must also be checked
- Using a syringe, fill the turbo with oil via the turbo oil inlet, then prime the turbine by hand.
- Once the new turbo has been fitted, start the engine and let it idle for 10 minutes. Before stopping the
engine, allow it to idle for a few seconds (do not accelerate suddenlybefore stopping)

Original reference OEM:

028 145 701 L
