4 Inlet valve 46x103,8x8mm for BMW 02 series E10 Sedan, Touring and Cabriolet Baur Targa with cylinder head number E12 or E21 2.0 :
Sedan :
- 2002 100hp phase 1 from 06/1972 to 08/1973 (engine code M05)
- 2002 100hp phase 2 from 09/1973 to 11/1975 (engine code M05)
- 2002A auto 100hp phase 1 from 06/1972 to 08/1973 (engine code M05)
- 2002A auto 100hp phase 2 from 09/1973 to 06/1975 (engine code M05)
- 2002tii 130hp phase 1 from 04/1971 to 06/1972 (engine code M15) --> with 121 or 121TI cylinder head modified with 46mm valves
- 2002tii 130hp phase 1 from 06/1972 to 08/1973 (engine code M15) --> with E12 cylinder head
- 2002tii 130hp phase 2 from 09/1973 to 11/1975 (engine code M15)
- 2002Turbo 170hp from 07/1973 to 07/1975 (engine code M31)
Touring :
- 2000 100hp phase 1 from 06/1972 to 08/1973 (engine code M05)
- 2000A auto 100hp phase 1 from 06/1972 to 09/1972 (engine code M05)
- 2002 100hp phase 2 from 09/1973 to 04/1974 (M05 engine code)
- 2000tii 130hp phase 1 from 01/1971 to 06/1972 (engine code M15) --> with 121 or 121TI cylinder head modified with 46mm valves
- 2000tii 130hp phase 1 from 06/1972 to 08/1973 (engine code M15) --> with E12 cylinder head
- 2002tii 130hp phase 2 from 09/1973 to 04/1974 (engine code M15)
Cabriolet Baur Targa :
- 2002 100hp phase 1 from 06/1972 to 08/1973 (engine code M05)
- 2002 100hp phase 2 from 09/1973 to 12/1975 (engine code M05)
INFORMATION: There are four different cylinder heads for the 2002 M10 engine. They are identified by a number which can be 121, 121TI, E12 or E21 2.0, located on the intake side, above the fourth cylinder inlet, easily visible when opening the hood.
From 01/1971 to 06/1972, the 2002tii is fitted with 121 or 121TI cylinder heads modified with 46mm valves. From 06/1972, all 2002s feature a new cylinder head identified E12 with 46mm intake valves.
Technical specifications:
- Head diameter: 46mm
- Stem diameter: 8mm
- Length: 103.8mm
- Seat angle: 45
- Shank type: 3 grooves
Quantity required: 4
This product is sold in packs of 4
