Valve timing kit

This set of timing tools is for vehicles from the Volkswagen Group equipped with 1.0  petrol engines.

Intended for the following VAG EA211 engines:

1.0 3 cylinders, engine: CHYA
1.0 TSI 3 cylinders, engines: CHZE, CHZC, CHZA, CHZB, CHZC, CHZD, CHZJ

Kit contents:

Camshaft adjustment plate. OEM T10494
Camshaft timing. OEM T10476
Crankshaft timing bolt. OEM T10340
Camshaft adjustment plate. OEM T10477
Adjustment wrench for tensioner, OEM T10499
Installation Tools. OEM T10487

TOOLATELIER tools to set the engine timing during the installation and removal of the camshaft, changing the timing chain, checking the engine timing and when changing the cylinder head gasket.

This kit also has a tool to lock the crankshaft, which is necessary when replacing the drive chains.

Suitable for the following BMW models:

- 1-Series : E81 / E82 /E87 / E88 / F20 => 116D - 118D - 120D - 123D
- 3-Series 3 : E90/ E91 / E92 / E93 / F30 => 316D - 318D - 320D - 325D and 330D
- 5-Series : E60 / E61 / F07 / F10 / F11 => 520D - 525D - 530D - 535D and GT- M550D
- 7-Series : F01 => 730D - 740D - 750D
- X1 : E84 => 1.8D - 2.0D - 2.3D
- X3 : F25 / E83 => 1.8D - 2.0d - 3.0D- 3.5D
- X5 : E70 => 3.0D - 4.0D - M5.0D
- X6 : E71 => 3.0D - 4.0D - M5.0D

Original reference:
OEM 116480
OEM 115320
OEM 118760

Ideal for locking camshafts and crankshafts when removing or fitting the timing chain on Opel and Vauxhall models.

Engine codes:

- 1.0 L => A10XEP (LDB)
- 1.2 L => A12XEL (LWD), A12XER (LDC)
- 1.4 L => A14XEL (L2Z), A14XER (LDD), LDU
- 1.4 L (T) => engines A14NEL (LUH), A14NET (LUJ), Twinport / ecoFLEX

Applications: Adam, Ampera, Astra-J, Aveo, Corsa-D, Insignes, Meriva-B, Mokka, Zafira-C Tourer

Contents:

- crankshaft locking pin
- camshaft adjustment plate
- tool to adjust the VVT sensor for 1.0L engines
- tool to adjust the VVT sensor for 1.2 and 1.4 L engines
- tool to hold the camshaft pinion
- tensioner locking pin (2 pieces)

Timing setting tools for Volkswagen Audi and Seat TDI from 2007.

Engine types: 1.6 and 2.0 TDI

Vehicle types:

- Audi
A3: 1.6 TDI (from 2009) Engine code CAYB/CAYC
A3, A4, A6, Q5: 2.0 TDI (from 2007) Engine code CBAB/CBBB/CBAA/CFFB/CAGA/CAHA/CAGB/CAHB/CAGC

- Volkswagen:
Golf, Golf Plus: 1.6 TDI (from 2009) Engine code CAYB/CAYC
Tiguan, Passat, Eos, Golf, Golf Plus: 2.0 TDI (from 2008) Engine code FCA/CAAA/CAAB/CAAC/CCHA/CAVA/CBAB/CBDA/CBDD/CBBB/CBAA/CBAC/CBDA/CBDC

- Seat:
Exeo: 2.0 TDI (from 2009) Engine code CAGA/CAHA/CAGA

Complete set of TOOLATELIERtiming tools designed to fit most Renault vehicles.

List of tools with their OEM part numbers:

MOT 1489, MOT 910, MOT 1054, MOT 1430, MOT 1318, MOT 1340, MOT 1135-01, MOT 1386, MOT 1348, MOT 1337, MOT 1312, MOT 1496, MOT 1384, MOT 1490-01, SCREW M6, SCREW M8

Examples of engines :

Petrol :
1.2 / 1.4 / 1.4 eco / 1.4 16v / 1.6 16v / 1.8 / 1.8 16v / 2.0 / 2.0 16v (including Sport and Williams) / 2.5 20v

Diesel :
2.2 D / 2.2 TD / 2.5 D / 2.5 TD / 1.5 DCI / 1.9 DCI

Example of vehicles with these engines:

Renault Twingo, Clio, Express Extra, Kangoo Rapid, R19, Mégane, Scenic, Laguna, Safrane, Trafic, Master, Espace, Logan Sandero, Note Micra.

Set of tools to synchronize timing chain engines.

Vehicle types: Agila / Astra G/H / Combo C / Corsa B/C/D / Meriva A / Tigra B

Engines: 1.0 / 1.2 / 1.4

Engine codes: X10XE / Z10XE / XEP / Z12XE / XEP / Z14XEL / XEP (1993-2010) / X10XE / Z10XE / Z10XEP / X12XE / Z12XE / Z12XEP / Z14XEL / Z14XEP

This TOOLATELIER chock tool kit is suitable for 2.0 FSi and TFSi vehicles from the VAG group:

Audi:

- A3 2.0 FSI SOHC (since 2003) Engine code: AXW, BHD, BMB
- A3 2.0 FSI (since 2004) Engine codes: AWA, AXX, BPY, BPY, BWA
- A4 2.0 TFSI (since 2004) Engine code: BUL
- A6 2.0 TFSI (since 2006) Engine code: BJP, BGB

Volkswagen:

- Golf 2.0 FSI SOHC (since 2003) Engine code: AXW
- Passat 2,0 TFSI (since 2005) Engine code: BWA, BWE, BGB, BPJ
- Touran 2,0 FSI SOHC (since 2003) Engine code: AXW

Contents:

- Locking pin, for use as OEM T10060A
- Locking rods, for use as OEM T10115
- Locking rods, to be used as OEM T40011
- Chain tensioner, use OEM 3366
- Camshaft lock, use as OEM T10252 Remember to retighten the tool's 2 hex screws before use, as there is a risk of breakage.
- Clamping screw, use as OEM T10092
- Pin wrench, use as OEM T10020

911 Carrera 4S 3.6 (2002), 996 3.4 (2002), Boxster 2.5 (1998), Boxster 2.7 (2000) Boxster 3.2 (2000)
With chassis 986, 987, 996,997
Supplied in storage case
OEM Refs: 9595, 9612, 9611,9634, 9608, 9602
Chain driven engines

Set of timing tools for engines from the VAG groupTSI / TFSI 1.4 & 1.6L.

Required to check and adjust the engine timing.

Suitable for the following vehicles/engines:

- Audi A3 (2003 to 2010)
- Seat Ibiza , Leon, Altea
- Skoda Octavia (2004 to 2009), Fabia (2007 to 2009), Superb (2009 to 2010), Roomster (2006 to 2009)
- VW Golf (2003 to 2009), Golf Plus (2005 to 2009), Jetta (2006 to 2009), Passat (2005 to 2009), Polo (2002 to 2008), Scirocco (2009 to 2010), Tiguan (2007 to 2009), Touran (2003 to 2009), Eos (2006 to 2009)

- Engine code AXU, BLG, BAG,BMY, BKG, BMK, BLF, CAVA, BLN, CAVB, BLP, CAVC, CAVE, CAVF, CAVD, CAXA, CAXC, CDGA, BTS

This case includes:

Camshaft timing tool, to be used like OEM T10171
Dial gauge support, to be used like OEM T10170
Crankshaft locking tool, to be used like OEM T10340
Timing tool for hydraulic tensioner, to be used like OEM T40011

This TOOLATELIER chock tool set is ideal for VAG models equipped with the 1.2 L 3-cylinder engine.

Applications :

Seat :
- Ibiza: 1.2 - 6 valves / 3 cylinders - engine codes: AWY / BMD - from 2002

Skoda :
- Fabia: 1.2 - 6 valves / 3 cylinders (55 bhp) - engine codes: AWY / BMD - from 2003

- Fabia: 1.2 - 12 valves (65 bhp) - engine codes: AZQ / BME - from 2003

Volkswagen :
- Polo: 1.2 - 6 valves / 3 cylinders(55bhp) - engine codes: AWY / BMD - from 2002

- Polo : 1.2 - 12 valves / 3 cylinders (65 bhp) - engine codes : AZQ / BME - from 2002



T10123 => Camshaft positioning tool
T10120 => Camshaft positioning tool
T10121 => Camshaft locking tool

Set of tools for Volkswagen, Audi, Seat and Skoda vehicles.

Engine types:

- 1.9 / 2.0L - TDI
- 1.9 - D
- 2.5 - V6 TDI
- 3.3 - V8TDI
- 1.2 - 3 cylinders
- 1.4 & 1.6 petrol

Engine codes: AFB / AKE/AKN / AYM / BAU / BCZ / BDG / BDH / BFC

Ideal to adjust:

- Engine flywheel
- Crankshaft
- Camshaft
- Injection pump
- Pulleys
- Setting the timing belt

Types of vehicles with these engines:

New Beetle, Borra, Caddy, Golf, Polo, Lupo, Jetta, Passat, Vento, Fabia, Octavia, Ibiza, Leon, Toledo, Cordoba, Arosa, A2, A3, A4,A5, A6, A8, 80, 90, 100, 200,Quattro, Allroad...

This set of TOOLATELIER timing tools is ideal for checking and positioning the camshaft for all work on valves, head gasket, etc. on New MINI and BMW N13 and N18 engines.

N13 B16 engines :

- 114i (F20) from 07/2012
- 116i (F20) from 09/2011
- 316i (F30) from 11/2012
- 118i (F20) from 09/2011
- 320i Efficient Dynamics (F30) from 11/2012

Engines N18 B16A:

- Roadster (R59) 1.6 163 hp from 2012-2015
- Roadster (R59) 1.6 200 hp from 2012-2015
- Coupe (R58) 1.6 163 hp from 2011-2015
- Coupe (R58) 1.6 200 hp from 2011-2015
- Clubman (R55) 1.6 163 hp from 2011-2014
- Clubman (R55) 1.6 200 hp from 2011-2014
- Countryman (R60) 1.6 163 hp from 2011-2017
- Countryman (R60) 1.6 200 hp from 2011-2017
- Mini (R56/57) 1.6 163 hp from 2011-2015
- Mini (R56/57) 1.6 200 hp from 2011-2015
- Paceman (R61) 1.6 200 hp from 2013-2017
- Countryman (R60) 1.6 190 hp from 2014-2017
- Paceman (R61) 1.6 190 hp from 2014-2017

Engines N18 B16A/M0:

- Mini (R56/57) 1.6 184 hp from 2010-2015
- Clubman (R55) 1.6 184 hp from 2010-2014
- Coupe (R58) 1.6 184 hp from 2011-2015
- Roadster (R59) 1.6 184 hp from 2012-2015


Engines N18 B16A/MO:

- Paceman (R61) 1.6 184 hp from 2013-2017
- Paceman (R61) 1.6 122 hp from 2013-2017
- Countryman (R60) 1.6 122 hp from 2013-2017
- Paceman (R61) 1.6 163 hp from 2013-2017

- is needed for replacing the cylinder head
sealing and motor timing
- suitable for the following Mini models:
One, HB Cooper, Cooper, series R55-56
with motor code N12
- crankshaft locking tool use as OEM 119590
-camshaft locking tool use as OEM 119540
- chain tensioner use as OEM 119340
- also suitable for:
Citroën C4 (08-09), C4 Picasso (08-09)
Peugeot 207 (06-09), 207CC (07-09), 308 (01-09)
with engine:
1,4 VTi (Valvetronic), EP3 (8FS) (Valvetronic)
EP6 (5FW), 1.6THP (Direct Injection), EP6DT (5FX)
EP6DTS(5FY)

Camshaft timing tools for Volkswagen, Audi, Seat and Skoda

Engine types: 1.9 TDi and SDi

Vehicle types: Beetle, Bora , Caddy, Golf, Polo

Engine codes: AGP / AGR / AHF / ALH / AQM / ASV / AYQ (1997-2005)

Original reference: 3418 - T20038

This TOOLATELIER timing tool kit replaces the timing chain on 2.7 and 3.0L TDI engines from the VAG Audi and Volkswagen groups.

For the following models:

AUDI :
- A4 2.7L TDI from 2001 to 2008 with BPP engine
- A4 2.7L TDI from 2001 to 2008 with BSG engine
- A4, A6, A8 3.0L TDI from 2005 with ASB engine
- A4 3.0L TDI from 2001 to 2008 with BKN engine
- A4, A5 3.0LTDI from 2007 with CAPA engine
- A6 ALLROAD ,A8 3.0L TDI from 2003 with BNG/BMK engine
- A6 ALLROAD 2.7L TDI from 2005 with BPP/BSG engine
- A6 and Q7 3.0L TDI from 2005 with BMZ/BUG/BUN engine
- A8 4.0L TDi from 2003 to 2010 with ASE engine

VOLKSWAGEN :
- PHAETON 3.0L TDI from 2004 with BMK/CARA engine
- TOUAREG 3.0 TDI from 2005 with BKS/BUN/CASA/B engine

This TOOLATELIER tool set is used for flywheel timing and camshaft alignment on BMW 3 Series from 1993 to 2001, 5 Series from 1994 to 1996, 7 Series from 1987 to 2002, 8 Series from 1990 to 1999 and Z3 from 1996 to 2003 with M40 and M70 petrol engines with chain and belt drive.

It also contains the camshaft locking tool and the crankshaft fixing bolt.

- 3 Series :
316i / 318i (E36): 1996-2001 - 1.6 L - Engine code: 16 4E 1
316i / 318i (E46): 1998-2001 - 1.6 L - Engine codes: 16 4E 2 / 16 E4E 3
- 5 Series :
518i (E34): 1994-1996 - 1.8 L - Engine codes: 18 4E 1 / 18 4E 2
- Series 7 :
750i (E32): 1987-1994 - 1.9 L - Engine code: 19 4E 1
750i (E38): 1994-2002 - 5.0 L - Engine code: 50 12 A
- 8 Series :
850i (E31): 1990-1999 - 5.4 L - Engine codes: 54 12 1 / 54 12 2
- Z3 (E36): 1996-2003 - 1.8 / 1.9 - Engine code: 56 12 1

Engine types 1.25 / 1.4 / 1.6 / 1.8 / 2.0L petrol:

For Ford:

Cougar (1998-01), Fiesta IV (1995-02), Fiesta V (2002-09), Fiesta VI (2008-15), Focus I (1998-05), Focus II (2005-11), Focus III (2011-14), Fusion (2002-12), Galaxy (2006-15), C-MAX (2003-10), B-MAX (2012-15), S-MAX (2006-15), Mondeo (1998-00), Mondeo III (2000-07), Mondeo IV (2007-14), Mondeo V (2014-15), Tourneo Connect (2002-06), Transit Connect (2002-06), Transit (2006-11)

Engine codes:

1.25: DHA | DHB | DHC | DHD | DHE | DHF | DHG | F8JA | F8JB | FUJA | FUJB | M7JA | M7JB | SNJA | SNJB | STJA | STJB
1.4 : ASDA | ASDB | FHA | FHE | FHD | FHF | FXDA | FXDB | FXDC | FXDD | FXJA | FXJB | FXJC | RTJA | RTJB | SPJA | SPJC | SPJD | UTJA
1.6 : FYDA | FYDB | FYDC | FYDD | FYDH | FYJA | FYJB | FYJC | HWDA | HWDB | L1F | L1J | L1L | L1N | L1Q | L1T | L1V | L1W | SHDA | SHDB | SHDC
1.8 : EYDB | EYDC | EYDD | EYDE | EYDF | EYDG | EYDI | EYDJ | EYDL | EYPA | EYPC | RKA | RKB | RKF | RKH | RKJ | RKK
1.8 (chain): CDBB | CGBA | CGBB | CHBA | CHBB | CSDA | CSDB | Q7DA | QQDA | QQDB | QQDC | QQDD | QQDE
2.0: ALDA | EDBA | EDBB | EDBC | EDBD | EDDB | EDDC | EDDD | EDDF | HMDA | NGA | NGB | NGC | NGD
2.0 (chain): AOBA | AOBC | AODA | AODB | AODE | AOWA | AOWB | CJBA | CJBB | N4JB | SYDA | TBBA | TBBB | TBWA | TBWB
2.3 (chain) : GZFA | GZFB | GZFC | SEBA | SEWA


For Mazda :

121 (1995-00), 2 (2002-07), 3 (BK) (2003-09), 3 (BL) (2009-14), 5 (CR) (2005-10), 5 (CW) (2010-15), 6 (GG/GY) (2002-07), 6 (GH) (2007-13), MPV (2002-05), MX-5 (NC) (2005-15), Tribute (EP) (2004-06)

Engine codes:

1.25 : DHA | F8JA | F8JB | FUJA | FUJB
1.4 : FXJB | FXJA
1.6 : FYJA
1.8 : L8
2.0 : LF
2.3 : L3 C1 166ch


For Volvo :

C30 (2006-13), S40 (2004-12), S80 (2007-11), V50 (2004-12), V70 (2007-11),

Engine codes:

1.6 : B4164S3
1.8 (chain) : B4184S11 | B4184S8
2,0 (chain) : B4204S3 | B4204S4

For the timing of VAG 1.2/1.4/1.9 and 2.0l TDI engines with pump injector (1998-2010) excluding 2.0l TDI 16S (oval crankshaft pulley)

12h blocking

Examples of vehicles: Passat, Audi A4, A6, Seat Alhambra, Altea, Arosa, Cordoba, Ibiza, Leon, Toledo, Golf 4 1,9 TDi (100, 115, 130 and 150 CV),Golf 5 1.9 TDi.

Contents:

- Crankshaft locking tool
- Pump locking pin Ø 6 mm
- Tensioner locking plate

Timing set for common rail diesel engines for Renault 2.0 DCi and CDTi.
For locking the camshaft and crankshaft during timing belt replacement or engine repair.

Vehicle types :

- Nissan Primaster (years 2008 - 2009), Qashqai (years 2008 - 2009), X-Trail (years 2007 - 2008) with engine code M9R 780, 830, 832, 833

- Renault Koleos (years 2008 - 2009), Laguna (years 2005 -2008), Megane (years 2007 - 2008), Scenic (years 2008 - 2009), Trafic (years 2007 - 2008), Vel Satis (years 2008 - 2009) with engine code M9R 700, 721, 724, 740, 742, 446, 760, 761, 780, 802,803,805, 830, 832, 833.

- Vauxhall, Opel Vivaro (years 2007 - 2008) with engine code M9R 780, 782, 784

Vehicle types :

Citroën :

Models : AX / AX GTi / ZX / BX / C15
Types : 1.0 / 1.1 / 1.4
Engine codes : CDY / CDZ / C1A / HDY / HDZ / H1A / HDX / KDY / KDZ / KFY / KFZ / K1A / K1F / K1G / K2A / K2B / K2D / K3B / K6B / M4A
Years: 1986 to 1994

Models: BX 15 - 16 - 19 / Visa GTi / ZX
Types: 1.6 / 1.9
Engine codes: BAY / B1A/A / B1E / B1F / B4A / B6D / B6E / BDY / DDZ / DFZ / DKZ / D2A / D2E / D2C / D2F / D6A / D6D / D6E / 159A / 171B / 171C / 171D / 180D / 180Z
Years: 1982 to 1994

Model: Saxo 16V
Type: 1.6
Engine code: NFX
Year: 1997

Peugeot :

Models: 106 / 205 / 309 / 405
Types : 1.0 / 1.1 / 1.4
Engine codes: TU1 / TU2 / TU3 / TU9
Years: 1987 to 1994

Models: 205 / 305 / 309 / 405
Types: 1.6 / 1.9
Engine codes: XU5-171B / 180A / B1E / B6D / XU9-D2A/D / D6A / D6B
Years: 1984 to 1992

Models: 309 GTi 16 / 405 Mi 16
Type: 1.6
Engine code: X12XE
Years: 1987 to 1994
