Valve

Angled drain - D20/31 mm.
Angled drain, with cap on chain.
White
Hose Ø 20 mm
Thread diameter (mm): 31

Angled drain - D25/31 mm.
Angled drain, with cap on chain.
White
Ø 25 mm hose
Thread diameter (mm): 31

Straight drain - D20/25 mm
With chain.
White
Hose Ø 20 mm
Thread diameter (mm): 25.
Outside Ø (mm): 50.
Ø cap (mm): 20.

Straight drain - D20/31 mm.
With chain.
White
Hose Ø 20mm
Thread diameter (mm): 31

Straight plug D25/31 mm
With small chain.
Color : white
Tube Ø 25 mm
Ø thread (mm): 31

Bung plug D20/31 mm.
Colour white

For BARWIG mixer hand shower.
Colour: grey.

Mixer and stopcock.
Ideal for adjusting the flow rate of shower heads.
Maximum water pressure: 2.5 bars.
Contactor: 15A.
Connections
- Inlet: nipple: for 10/12 mm screw-in hose.
- Outlet: threaded 15x21 mm.
Bore Ø 20mm (max. plate thickness 25 mm).

Barwig 6055-20

Max. pressure 5 bar
Maximum amp capacity: 15 A
Suitable for plate thicknesses up to 25 mm.
Fitting for 10 mm or 3/8' threaded hose. Bore Ø 20mm.

STYLE 2005 REICH mixer tap;
For motorhomes, caravans, boats.
Folding tap with contactor (4 A max.) operating on low 12 V voltage.
Permissible water pressure: 3 bar.
Mounting on ø 10 or 12 nipples, or quick couplings.
Chrome colour.
Folded height: 40 mm.
Drilling diameter: 20 mm.
Cable length: 350 mm.
Weight: 130 g.

Reich 547-050000

Compatible with Duette Standard/Konus and Reich De Luxe handhelds.
For cold water supply only.
Installation depth: 90 mm
Drilling diameter: 20 mm (max.20 mm thick plate)
Colour: White
Fitting(s): 1/2'' (15x21)
Weight: 125 g

Compact and adjustable, this mixer is appreciated by owners of motor homes or vans that suffer from a lack of space. It is not foldable. Resistant to pressures up to 3 bars and is equipped with a contactor. Equipped with 2 buttons for hot and cold water, you set the desired amount of water.
Permissible water pressure: 3 bar.
Mounts on ø 10 or 12 mm nipples.
Colour: White.
Single hole.

Its tilting and swivelling output is highly appreciated by motor home and van owners and is equipped with a switch to withstand pressures of up to 3 bars. Equipped with 2 buttons for hot and cold water, you set the desired amount of water.
Permissible water pressure: 3 bar.
Mounts on ø 10 or 12 mm nipples.
Colour: Matte nickel-plated, crystal adjustment knob.
Length of thread: 25 mm.
Hole diameter: 2 x 20 mm with 75 mm centre distance.
Evacuation length: 160 mm.
Weight: 170 g.

STYLE 2005 REICH mixer tap;
For motorhomes, caravans, boats.
Folding tap with contactor (4 A max.) operating on low 12 V voltage.
Permissible water pressure: 3 bar.
Mounting on ø 10 or 12 nipples, or quick couplings.
Colour: white.
Folded height: 40 mm.
Drilling diameter: 20 mm.
Cable length: 350 mm.
Weight: 130 g.

TWIST REICH Keramik mixer tap.
For motorhomes and caravans.
Folding mixer tap with replaceable ceramic cartridge and contactor (4 A max.) operating on low 12 V voltage.
Chrome colour.
Permissible water pressure: 3 bar.
Mounting on ø 10 or 12 nipples, or quick couplings.
Folded height: 40 mm.
Hole diameter: 39 mm.
Cable length: 350 mm.
Weight: 230 g.

Chrome-plated mixer tap.
- With ceramic cartridge.
- Waterproof IP 67 (4A max) class contactor operating on low voltage 12V.
- Maximum water pressure: 3 bars.
Finish: chrome-plated.
- Dimensions. Bore: Ø 27 mm Height (folded): 40 mm.
- Weight: 150 g.
- Attaches to tray with a maximum thickness of 30 mm.
Mounting on Ø 10 or 12 nipples or quick couplings.
Comes with contactor.

REICH: 553-040000.

TREND REICH chrome-plated gooseneck mixer.
- With ceramic cartridge.
- Waterproof IP 67 (4A max) class contactor operating on low voltage 12V.
- Maximum water pressure: 6 bar.
- Shape: gooseneck.
Finish: chrome-plated.
- Dimensions. Bore: Ø 33 mm Height: 315 mm. Length of spout: 190 mm.
- Weight: 400 g.
- Attaches to tray with a maximum thickness of 36 mm.
Mounts on Ø 10 or 12 nipples or quick couplings.
Comes with contactor.

REICH: 571-902000

FLORENZ chrome-plated automatic single lever tap with 17cm spout, single lever, 8/10mm flexible nylon connectors, weight of 250 g, 33 mm attachment hole. Mounting height 40 mm.
With ceramic cartridge and waterproof switch.
Weight: 0.25 kg.COMET: S2351.20.21

The KERAMIK DELUXE REICH mixer tap is ideal for integration into the kitchen of a motorhome, caravan or van. With its ceramic ring, it features a micro-switch. Conveniently, the fold-away spout can be uncoupled and allows the installation of a 1/2" female thread hand shower.

Features:
Drill hole: 27 mm.
Connection type: standard A.
Height external dimensions: 4 cm.
Cable length: 0.3 m.
Microswitch: 4 A.
Worktop thickness: 28 mm.
Max. water pressure: 3 bar.
Spout length: 155 mm.
With contactor.
Weight: 165 g.

STYLE 2005 REICH mixer tap;
For motorhomes, caravans, boats.
Folding tap with contactor (4 A max.) operating on low 12 V voltage.
Permissible water pressure: 3 bar.
Mounting on ø 10 or 12 nipples, or quick couplings.
Colour: Matte nickel-plated.
Folded height: 40 mm.
Drilling diameter: 20 mm.
Cable length: 350 mm.
Weight: 130 g.
