Flanges

For 40 or 45 DCOE,by mounting from above.

Kit sold with 175 needle

Double flange under a WEBER 40 or 45 DCOE carburettor.

The vibrations of prepared engines are harmful to the carburetor and its settings. Protect your carburetors by installing this set of vibration dampers.
WEBER DCOE carburettor baseplate gasket for watertight mounting between intake pipe and carburettor.
Designed for DCOE versions 40 and 45, this gasket can also be used on 48 carburetors (although the aluminum O-ring flange is more suitable for 48 carburetors).

Ideal for sealing 40mm and 45mm rigid flanges on Weber 40/45 DCOE carburetors.

Gasket for BANJO connection on WEBER 40, 45 or 48 DCOE.
Sold individually for inner side (towards carburettor).

Seal for BANJO fitting on WEBER 40, 45 or 48 DCOE.
Sold individually for the outer side

1 40 mm aluminum flange for Weber 40 DCOE carburetor.
This flange is positioned between the carburetor and the intake pipe.

Inside diameter: 40 mm
Flange thickness: 6 mm
Material: Aluminum

Requires 2 UC40264 O-rings (not supplied).
Need 2 flanges to equip 1 carburetor.

For Weber 45DCOE carburettor

This cup is positioned between the carburettor and the intake manifold.

Material: Aluminium

Requires 2 UC40264 O-rings

For Weber 45DCOE carburettor

This cup is positioned between the carburettor and the intake manifold.

Material: Aluminium

Requires 2 UC40264 O-rings

Oval filter with filter foam to equip a pair of win carburettors, type 40 or 45 WEBER DCOE or Dellorto.
This filter is designed to provide maximum protection and efficiency, with a minimum size if space is restricted to pass your carburettors in the engine compartment.
Dimensions:
435 mm long x 190 mm wide
Overall height 90 mm, interior height 65 mm

The filter is secured (with 3 dzus fasteners, supplied) to an aluminium plate, pre-drilled or solid, type UC70311, not included. (sold as an option).

Oval filter with filter foam to equip a pair of win carburettors, type 40 or 45 WEBER DCOE or Dellorto.
This filter is designed to provide maximum protection and efficiency, with a minimum size if space is restricted to pass your carburettors in the engine compartment.
Dimensions:
435 mm long x 190 mm wide
Overall height 120 mm, interior height 90 mm

The filter is secured (with 3 dzus fasteners, supplied) to an aluminium plate, pre-drilled or solid, type UC70311, not included. (sold as an option).

Air filter gasket for Weber 40 DCOE.

Joint de filtre à air pour carburateur Weber 45 DCOE.

Set sold with a 200 needle

Enables the synchronisation of 2 DCOE gas controls, side-by-side

Support plate for PIPERCROSS air filter, type UC70312/13/14

Support plate, not drilled, made from aluminium.
This plate has the same shape as the Oval filter, the sides are designed to attach Dzus type fasteners.

Ce raccord banjo en "T" permet le montage d'une rampe de carburateur pour 2 Weber DCOE.

Sold per unit

Weber double-cable DCOE accelerator control.
Installation above the carburettor for 2 DCOE.

This set is supplied with two cables and the necessary peripherals for fixing.

High-quality throttle linkage for lower mounting of 1 or 2 Weber DCOE or DCO/SP carburetors.

Lower mounting of the control linkage is particularly recommended where space is at a premium.

This kit is supplied without cables, as it is designed for use with original cables.
