Damper pulley

Damper pulley.Crankshaft vibration damper for VW Transporter T4 since 01/1995 :- 2.4 Diesel 78hp (AAB) since engine n°320127
For VW Transporter T4 since 01/1996 :- 2.4 Diesel 75hp (AJA)- 2.4 Diesel 78hp (AAB)- 2.5 TDi 88hp (AJT, AYY)- 2.5 TDi 102hp (ACV, AUF, AYC, AXL)- 2.5 TDi151hp (AHY, AXG)

Damper pulley, crankshaft vibration damper for VW LT from 1996 to 2006 :
- 2.5 SDi 75hp (AGX)
- 2.5 TDi 83hp (BBE) up to engine no. 002146
- 2.5 TDi 90hp (APA)
- 2.5 TDi 95hp (BBF) up to engine no. 002468
- 2.5 TDI 102hp (AHD)
- 2.5 TDi 109hp (ANJ) up to engine no. 054792

TOPRAN Damper pulley.Crankshaft vibration damper for VW Transporter T4 since 01/1995 :- 2.4 Diesel 78hp (AAB) since engine n°320127
For VW Transporter T4 since 01/1996 :- 2.4 Diesel 75hp (AJA)- 2.4 Diesel 78hp (AAB)- 2.5 TDi 88hp (AJT, AYY)- 2.5 TDi 102hp (ACV, AUF, AYC, AXL)- 2.5 TDi151hp (AHY, AXG)

For Saloon:
- 2.5 TDi (AAT)

For Avant:
- 2.5 TDi (AAT)
- 2.5 TDi 140 hp (AEL) including Quattro

Crankshaft pulley with vibration dampers brand TOPRAN for BMW series 3 E46 Sedan,Touring,Coupeand Cabrioletphase 2 with 6-cylinder diesel 204hp engine :

Berline:
- 330d 204hp phase 2 from 08/2002 to 02/2005 (engine code M57D30TU)
- 330xd 204hp phase 2 from 09/2002 to 12/2004(engine code M57D30TU)

Touring:
- 330d 204hp phase 2 from 09/2002 to 07/2005 (engine code M57D30TU)
- 330xd 204hp phase 2 from 08/2002 to 05/2005 (engine code M57D30TU)

Coupé:
- 330cd 204hp phase 2 from 08/2002 to 05/2006 (engine code M57D30TU)

Cabriolet:
- 330cd 204hp phase 2 from 11/2004 to 08/2006 (engine code M57D30TU)

Number of grooves (1): 4
Number of grooves (2): 6
Outer diameter (1): 170 mm
Outer diameter (2): 192 mm
Height: 73 mm

Delivered without mounting screws.

During the assembly, it is imperative to respect the tightening torque (see manual) but also to replace the 4 fixing screws of the pulley (reference BC35976 to be ordered separately on our site).
Don't forget to put back the spacer washer present on your old damper pulley.

Crankshaft pulley with vibration dampers for Bmw X5 : Bmw X5 E70 : - 3.0D 6cyl 235hp from 02/2006 to 03/2010 (engine code m57d30n2)
- 3.0SD 6cyl 286hp from 01/2007 to 03/2010 (engine code m57d30n2 Bi-Turbo)
Bmw X5 E70 Lci : - 35XD USA 6cyl 245hp from 08/2009 to 06/2013 (engine code m57d30n2)
Supplied without mounting screws .

During assembly, it is imperative to respect the tightening torque (see manual) and also to replace the 4 pulley fixing screws (part no. BC35976, to be ordered separately on our site).
Don't forget to replace the spacer washer on your old damper pulley.

Crankshaft pulley with vibration damper,

For E90 & E91:
- 325 d M57N2
- 330 d/xd M57N2
- 335 d M57N2

For E92 & E93:
- 325 d M57N2
- 330 d M57N2
- 330 xd M57N2 (E92 only)
- 335 d M57N2 (E92 only)

For E90 LCI, E91 LCI & E92 LCI:
- 325 d M57N2 (except E92)
- 335 d M57N2

Crankshaft pulley with vibration damper,

For E60 & E61:
- 525 d M57N
- 530 d M57N
- 530 d/xd M57N2
- 535 d M57N

For E60 LCI & E61 LCI:
- 525 d/xd M57N2
- 530 d/xd M57N2
- 535 d M57N2

For X5 E53:
- 3.0 d M57N

Damper pulley for BMW X3 E83 and LCI 6-cylinder diesel:

BMW X3 E83 :

- 3.0d 6cyl 204hp from 01/2003 to 08/2005 (engine code M57D30TU)
- 3.0d 6cyl 218hp from 03/2005 to 07/2006 (engine code M57D30TU)

BMX X3 E83 LCI :

- 3.0d 6cyl 218hp from 03/2006 to 06/2008 (engine code M57D30TU)
- xDrive30d 6cyl 218hp from 07/2008 to 08/2010 (engine code M57D30TU)
- 3.0sd 6cyl 286hp from 03/2006 to 06/2008 (engine code M57D30TU2TOP) --> bi-turbo
- xDrive35d 6cyl 3.0L 286hp from 07/2008 to 08/2010 (engine code M57D30TU2TOP) --> twin-turbo 3.0d engine
- xDrive30d 6cyl 218hp from 07/2008 to 08/2010 (engine code M57D30TU)

Supplied without mounting screws.

When fitting, it is essential to observe the tightening torque (see manual) and also to replace the 4 pulley fixing screws (part no. BC35998, to be ordered separately on our site).
Don't forget to replace the spacer washer on your old damper pulley.

Crankshaft pulley with vibration dampers for BMW 3 Series E46 Sedan, Touring, Coupé, Cabriolet and Compact phase 2 with 4-cylinder diesel engine:

Sedan :
- 318d 4cyl 116hp phase 2 from 03/2003 to 01/2005 (engine code M47D20TU)
- 320d 4cyl 150hp phase 2 from 03/2001 to 05/2005 (engine code M47D20TU)

Touring :
- 318d 4cyl 116hp phase 2 from 10/2001 to 07/2005 (engine code M47D20TU)
- 320d 4cyl 150hp phase 2 from 10/2000 to 07/2005 (engine code M47D20TU)

Coupé :
- 320cd 4cyl 150hp phase 2 from 03/2003 to 05/2006 (engine code M47D20TU

Cabriolet :
- 320cd 4cyl 150hp phase 2 from 01/2005 to 08/2006 (engine code M47D20TU)

Compact :
- 318td man. 4cyl 115hp phase 2 from 01/2003 to 12/2004 (engine code M47D20TU)
- 320td 4cyl 150hp phase 2 from 04/2003 to 12/2004 (engine code M47D20TU)

Number of grooves (1) : 4
Number of grooves (2) : 6
Outside diameter (1): 172 mm
Outside diameter (2): 195 mm
Inside diameter (1): 18 mm
Inside diameter (2): 24 mm
Height: 66 mm

Supplied without fixing screw.

During assembly, it is imperative to observe the tightening torque (see instructions) and also to replace the central fixing screw (order no. BC35986 separately from our site).
Don't forget to replace the spacer washer on your old damper pulley.

Crankshaft pulley for BMW X3 E83 with 4-cylinder diesel engine:
X3 E83 and E83 LCI :
- 2.0d 4cyl 150hp from 05/2003 to 07/2006 (engine code M47D20TU) - 2.0d 4cyl 150hp from 03/2006 to 08/2007 (engine code M47D20TU)
Fixing screws included.
When fitting, it is essential to observe the tightening torque, and also to replace the central fixing screw.Don't forget to replace the spacer washer on your old damper pulley.

Crankshaft pulley with vibration dampers for BMW 5 Series E60, E60LCI Sedan and E61, E61LCI Touring :
E60 :- 520d 4cyl 163hp from 02/2005 to 02/2007 (engine code M47D20TU2)
E60LCI :- 520d 4cyl 177hp from 11/2006 to 02/2008 (engine code M47D20TU2)
E61 :- 520d 4cyl 163hp from 04/2005 to 02/2007 (engine code M47D20TU2)
E61LCI :- 520d 4cyl from 05/2006 to 02/2008 (engine code M47D20TU2)
During assembly, it is imperative to observe the tightening torque (see manual) and also to replace the central screw (part no. BC35985, to be ordered separately on our site).Don't forget to replace the spacer washer on your old damper pulley.
Fixing screw included.

Crankshaft pulley with vibration dampers for BMW 1 series E87 Sedan 5 doors phase 1 :
- 118d 122hp from 02/2003 to 02/2007 (engine code M47D20TU2) - 120d 163hp from 03/2003 to 02/2007 (engine code M47D20TU2)
During assembly, it is essential to observe the tightening torque (see manual), and also to replace the central screw (part no. BC35983, available separately on our website).Don't forget to replace the spacer washer on your old damper pulley.
Fixing screw included.

Crankshaft pulley with vibration dampers for BMW 3 Series E90 Sedan and E91 Touring phase 1 :
E90 :- 318d 4cyl 122hp from 02/2004 to 08/2007 (engine code M47D20TU2)- 320d 4cyl 163hp from 02/2004 to 09/2007 (engine code M47D20TU2)
E91 :- 318d 4cyl 122hp from 09/2005 to 08/2007 (engine code M47D20TU2)- 320d 4cyl 163hp from 02/2004 to 08/2007 (engine code M47D20TU2)
During assembly, it is imperative to observe the tightening torque (see manual) and also to replace the central screw (part no. BC35984, to be ordered separately on our site).Don't forget to replace the spacer washer on your old damper pulley.
Fixing screw included.

For Audi 80 (8C2):
- 1.9 Turbo Diesel 75hp (AAZ)
- 1.9 TDi 90hp (1Z)

For A6 (C4):
- 1.9 TDi 90hp (1Z, AHU)

Damper pulley, vibration damper on crankshaft

For VW Transporter T4 type 70/7D
02/1993 ->06/2003
since chassis no. 70-P-085001->
Engines:
- 1.9 Diesel 60hp (1X)
- 1.9 Diesel 68hp (ABL)

Damper pulley, crankshaft vibration damper.

Compatible with Seat Ibiza type 6K:
- 1.9 Diesel 64 hp (1Y, AEY)
- 1.9 Turbo Diesel 75 hp (AAZ)
- 1.9 TDi 90 hp (1Z, AHU)
- 1.9 TDi 110 hp (AFN)

For Golf 3 (including Syncro, estateand cabriolet):
- 1.9 Diesel 64hp (1Y)
- 1.9 turbo Diesel 75hp (AAZ)
- 1.9 TDi 90hp (1Z, AHU, ALE)
- 1.9 TDi 110hp (AFN, AVG)

For Passat 3:
- 1.9 turbo Diesel 75hp (AAZ)
- 1.9 TDi 90hp (1Z, AHU)
-1.9 TDi 110hp (AFN)

For Polo Classic (6V2):
- 1.7 SDi 60hp (AKW)
- 1.9 Diesel 64hp (1Y, AEY)
- 1.9 TDi 90hp (AHU, ALE)
- 1.9 TDi 110hp (AFN)
